|Form Factor:||10Gbps XFP Optical Transceiver||Data-rate:||10GBASE-ER|
|Form-factor:||XFP Optical Transceiver||Connector:||LC|
fiber optic transceiver,
transceiver fiber optic
80KM 1550nm SM XFP 10g Optical Transceiver
10Gbps XFP Optical Transceiver, 80Km Reach
♦ XFP MSA Compliant
♦ Data rate from 9.95 Gbps to 11.1Gbps
♦ No Reference Clock required
♦ Cold Start up Wavelength Compliance
♦ EML transmitter and APD receiver
♦ Link length up to 80km
♦ Low Power Dissipation 3.5W Maximum
♦ -5ºC to 70ºC Operating Case Temperature
♦ Diagnostic Performance Monitoring of module temperature, supply
♦ Voltages, laser bias current, transmit optical power, receive optical power
♦ RoHS compliant and lead free
♦ SONET OC-192&SDH STM 64
♦ 10G Ethernet
♦ 80 km 10G Fiber Channel
Gezhi's XFP Transceiver is designed for 10G SDH, 10G ZR and 10G Fiber- Channel applications.
The transceiver consists of two sections: The transmitter section incorporates a colded EML laser. And the receiver section consists of a APD photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. XFP transceiver provides an enhanced monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
|Part Number||Product Description|
|GX-H155-ZRC||1550nm, XFP, 10Gbps, 80km, 0ºC ~ +70ºC|
