8CH CWDM OADM Modules Duplex Fiber

8CH CWDM OADM Modules Duplex Fiber
8CH CWDM OADM Modules Duplex Fiber

Large Image :  8CH CWDM OADM Modules Duplex Fiber

Product Details:
Place of Origin: China
Brand Name: GEZHI or OEM
Certification: CE/RoHS/ISO9001
Model Number: CWDMO8CHWED4591LP
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Get Latest Price
Packaging Details: paper box with foam
Delivery Time: 5~8work days
Payment Terms: T/T, Paypal,Western Union
Supply Ability: 100000 Channel per month
Detailed Product Description
Product Name: CWDM OADM Fiber: 1meter
Cable: 900um Loose Tube Connector: LC/PC
Wavelength: 1470~1610nm Type: W+E Dual Fiber
High Light:

sfp optical transceivers

,

sfp fiber optic transceiver

8CH CWDM OADM Modules Duplex Fiber



The 8CH CWDM OADM Modules Duplex Fiber of GEZHI is a passive optical add/drop multiplexer designed for point-to-point, ring, or bus configurations' applications that provides the ideal solution for the increasing bandwidth demand on enterprise and metro access networks and delivers dramatic cost savings to network equipment manufacturers, enabling them to develop metro access systems that are lower in cost, easier to provision and simpler to operate.



Features

Applications

  • Low Insertion Loss
  • Flexible OADM networking
  • Dual-sided East and West
  • No electric power required
  • Optical Add and Drop
  • WDM Network
  • Cellular Application
  • Telecommunication
  • Acess Network



Specification

Parameter



Unit

8CH CWDM OADM
Add Drop
Channel Wavelength nm 1470~1610nm

Center wavelength

Accuracy

nm ±0.5
Channel Spacing nm 20

Channel Passband

(@-0.5dB bandwidth

nm >13
Insertion Loss dB <2.5 <2.5
Channel Ripple dB 0.3
Isolation Adjacent dB >30
Non-adjacent dB >40

Inertion Loss Temperature

Sensitivity

dB/℃ <0.005

Wavelength Temperature

Shifting

nm/

<0.002

Polarization Dependent

Loss

dB <0.1

Polarization Mode

Dispersion

dB <0.1
Directivity dB >50
Return Loss dB >45
Maximum Power Handling mW 300
Opterating Temperature -20~+70
Storage Temperature -40~85
Package dimension mm 140x115x18



Note: 1. Customization is available.

2. Specified with connector





Ordering Information

CWDM XX X XX X X XX
 OADM Number of Channels

Confi

-guration

1st Channel Fiber Type Fiber Length In/Out Connector



04=4 Channel

08=8 Channel

16=16 Channel

18=18 Channel

N=N Channel



S=Single Fiber

D=Dual Fiber



27=1270nm

……

47=1470nm

49=1490nm

……

61=1610nm

SS=special



1=Bare fiber

2=900um loose tube

3=2mmCable

4=3mmCable



1=1m

2=2m

S=Specify



0=None

1=FC/APC

2=FC/PC

3=SC/APC

4=SC/PC

5=ST

6=LC

S=Specify
