40km Single Mode BIDI SFP Transceiver OC-3 / STM-1 / Fast Ethernet 1000base

40km Single Mode BIDI SFP Transceiver OC-3 / STM-1 / Fast Ethernet 1000base

GEZHI WDM / BIDI small form-factor pluggable (SFP),  such as: Bi-directional optics, BX-U / BX-D, WDM, Single Fiber and so on. BIDI SFP can be produced either with SC or LC simplex port, that is used both transmission and receiving. The most typical wavelength combination is 1310/1550, 1310/1490, 1490/1550 and 1510/1570.

For a link you need 2 different optics, one that sends 1310nm and receives 1550nm and the other side of the fiber, which has a Bidi optic which sends 1550nm and receives 1310nm. In most cases these wavelengths are mentioned as Tx (transmitting) and Rx (receiving) on the label of the optic.

Features

• Dual data-rate of 1.25Gbps/1.063Gbps operation
• 1550nm FP laser and PIN photodetector for 40km transmission
• Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
• Digital Diagnostic Monitoring
• Compatible with SONET OC-24-LR-1
• +3.3V single power supply
• Operating case temperature range of 0°C to +70°C (Commercial)

Application

• Gigabit Ethernet/Fast Ethenet
• Switch to Switch interface
• SDH/SONET/ATM
• Fiber Channel
• Router/Server interface
• Other optical transmission systems

Specification:

Competitive Advantages

1. Excellent quality and 3 years warranty
2. Competitive pricing
3. OEM/ODM Customized label
4. Keep stock,Fast delivery
