40 Channel Gaussian Dense Wave Division Multiplexer , 200Ghz Awg Multiplexer

40 Channel Gaussian Dense Wave Division Multiplexer , 200Ghz Awg Multiplexer
40 Channel Gaussian Dense Wave Division Multiplexer , 200Ghz Awg Multiplexer

Large Image :  40 Channel Gaussian Dense Wave Division Multiplexer , 200Ghz Awg Multiplexer

Product Details:
Place of Origin: China
Brand Name: GEZHI or OEM
Certification: CE/FCC/RoHS/TUV/UL
Model Number: GZ-40CH Athermal Gaussian AWG
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Get Latest Price
Packaging Details: 1pcs in a foam with paper box
Delivery Time: 2~7working days
Supply Ability: 80000Channel per month
Detailed Product Description
Product Name: Gaussian Athermal AWG Module Channel Number: 40 Channels
Wavelength: ITU Grid Connector: LC/SC/FC/ST (PC Or APC)
Fiber Type: Simplex Application: DWDM Transmission Network
High Light:

dense wave division multiplexer

,

fiber optic multiplexer


40 Channel Gaussian Dense Wave Division Multiplexer , 200Ghz Awg Multiplexer


GEZHI Photonics offers a full range of Thermal/Athermal AWG products, including 50GHz, 100GHz and 200GHz Thermal/Athermal AWG. Here we present the generic specification for the Fiber Optic Passive 40channels 200Ghz Gaussian DWDM AWG Mux Demux component supplied for use in DWDM system.



Athermal AWG (AAWG) have equivalent performance to standard Thermal AWG(TAWG) but require no electrical power for stabilization. They can be used as direct replacements for Thin Film Filters(Filter type DWDM module) for cases where no power is available, also suitable for outdoor applications over -30 to +70 degree in access networks.



GEZHI Photonics’ Athermal AWG (AAWG)provide excellent optical performance, high reliability, ease of fiber handling and power saving solution in a compact package. Different input and output fibers, such as SM fibers, MM fibers and PM fiber can be selected to meet different applications. We can also offer different product packages, inluding special metal box and 19” 1U rack mount.



The planar DWDM components (Thermal/Athermal AWG) Fiber Optic Passive 40channels 200Ghz Gaussian DWDM AWG Mux Demux from GEZHI Photonics are fully qualified according to Telcordia reliability assurance requirements for fiber optic and opto-electronic components (GR-1221-CORE/UNC, Generic Reliability Assurance Requirements for Fiber Optic Branching Components, and Telcordia TR-NWT-000468, Reliability Assurance Practices for Opto-electronic Devices).


Front Panel Details
40 Channel Gaussian Dense Wave Division Multiplexer , 200Ghz Awg Multiplexer 0


A Common port:

  • LC, SC, ST and FC connectors available.

B Monitor port:

  • Connects measurement/monitoring equipment, such as power meters or network analyzers, to the module outputs. When finished monitoring, disconnect the instruments and the network is left undisturbed
  • LC, SC, ST and FC connectors available.
  • Tap percentage is 5% as default, 1%, 2%, 3%, or 10% available on request.

C Express port:

  • Enables the cascading of two DWDM mux/demux modules, doubling the channel capacity on the common fiber link.
  • Isolation is less than 15dB as default, 16dB ~40dB available on request.
  • LC, SC, ST and FC connectors available.

D Standard port 1310nm:

  • Allows a legacy 1310nm signal to pass. That is to say, it can carry LR optics, LX optics etc.
  • LC, SC, ST and FC connectors available.

E Mux/Demux port for specific ITU-Grid channels:

  • LC, SC, ST and FC connectors available.

Item Details
  • Fiber Optic Passive 40channels 200Ghz Gaussian DWDM AWG Mux Demux
  • The channel spacing for DWDM is 0.8 nm (100 GHz grid). 1.6nm (200GHz) also available on request.
  • Aluminum pigtailed module
  • Protocol transparent (10 Mbps to 100 Gbps)
  • Distance: Up to 80 km depending on power budget of user equipment
  • Low insertion loss
  • Excellent channel isolation
  • Epoxy-free optical path
  • Compliant to ITU-T G.657A1 standard.
  • ISO 9001 manufacturing facility

Mechanical Details for Housing  ( Using Aluminum Box)
40 Channel Gaussian Dense Wave Division Multiplexer , 200Ghz Awg Multiplexer 1

Note: Please, note that the drawings shown here only show the dimensions and do not the specific configuration of the module.
