10GBASE-CWDM 10G BIDI SFP Transceiver Duplex LC 1270-1610 nm CWDM SFP

10GBASE-CWDM 10G BIDI SFP Transceiver Duplex LC 1270-1610 nm CWDM SFP
10GBASE-CWDM 10G BIDI SFP Transceiver Duplex LC 1270-1610 nm CWDM SFP

Large Image :  10GBASE-CWDM 10G BIDI SFP Transceiver Duplex LC 1270-1610 nm CWDM SFP

Product Details:
Place of Origin: China
Brand Name: GEZHI or OEM
Certification: CE/FCC/RoHS/TUV/UL
Model Number: /
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Get Latest Price
Packaging Details: 10 or 20pcs in Plastic tray
Delivery Time: 1~3working days after payment
Payment Terms: T/T, Paypal,Western Union
Supply Ability: 60,000pcs per month
Detailed Product Description
Product Name: CWDM SFP Module Datarate: 10Gb/s
Wavelength: CWDM 1270~1610nm Distance: 40km
Connector: Duplex LC Application: 10Gbase WDM System
High Light:

sfp fiber optic transceiver


sfp transceiver modules

10GBASE-CWDM 10G BIDI SFP Transceiver Duplex LC 1270-1610 nm CWDM SFP


10GBASE-CWDM SFP+ Transceiver CWDM SFP  40km SM Duplex LC 1270~1610nm


The GEZHI CWDM SFP small form-factor pluggable (SFP) is a compact optical transceiver used in optical communications for both telecommunication and data communications applications on the CWDM SFP 1270, CWDM SFP 1290, CWDM SFP 1310, CWDM SFP 1330, CWDM SFP 1350, CWDM SFP 1370, CWDM SFP 1390, CWDM SFP 1410, CWDM SFP 1430, CWDM SFP 1450, CWDM SFP 1470, CWDM SFP 1490, CWDM SFP 1510, CWDM SFP 1530, CWDM SFP 1550, CWDM SFP 1570, CWDM SFP 1590, CWDM SFP 1610. wavelength.SFP transceivers are designed to support SONET/SDH, Gigabit Ethernet, Fibre Channel, and other communications standards SFP transceivers are available with a variety of different transmitter and receiver types, allowing users to select the appropriate transceiver for each link to provide the required optical reach over the available optical fiber. SFP transceivers are commercially available with capability for datarates up to 10 Gbit/s SFP+.




Compliant with SFF-8431 and IEE802.3ae

Data rate selectable ≤4.25Gbps or 9.95Gbps to 10.3Gbps bit rates
Cooled EML transmitter and PIN receiver
♦ Wavelength selectable to ITU-T standards covering CWDM grid wavelengths
link length up to 40km
♦ Low Power Dissipation 1.5W Maximum
-5ºC to 70ºC Operating Case Temperature
Single 3.3V power supply
Diagnostic Performance Monitoring of module temperature, supply Voltages, laser bias current, transmit optical power, receive optical power
♦ RoHS compliant and lead free




10GBASE-ER at 10.3125Gbps

10GBASE-EW at 9.953Gbps

Other optical links




P/N /
Datarate 10Gb/s
Wavelenght CWDM 1270~1610nm
Distance 40km
Transmitter EML
Receiver PIN
Media SMF
Operating Temperature 0°C to +75°C
