| Product Name: | 10G SFP Module | Datarate: | 10Gb/s |
|---|---|---|---|
| Wavelength: | 1550nm | Distance: | 40km |
| Connector: | Duplex LC | Application: | 10Gbase Optical Transmission System |
| High Light: | sfp fiber optic transceiver,sfp transceiver modules |
||
10GBASE-ER SFP+ transceiver module for SMF, 1550-nm, 40km, LC duplex connector
The SFP is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms.
Features:
♦ Compliant with SFF-8431 and IEE802.3ae
♦ Data rate selectable ≤4.25Gbps or 9.95Gbps to 11.3Gbps bit rates
♦ Cooled EML transmitter and PIN receiver
♦ link length up to 40km
♦ Low Power Dissipation 1.5W Maximum
♦ -5ºC to 70ºC Operating Case Temperature
♦ Single 3.3V power supply
♦ Diagnostic Performance Monitoring of module temperature, supply Voltages, laser bias current, transmit optical power, receive optical power
♦ RoHS compliant and lead free
Application
♦ 10GBASE-ER/EW (with/without FEC)
♦ 10G Fiber Channel (with/without FEC)
♦ Other optical links
Specification:
| P/N | / |
| Datarate | 10Gb/s |
| Wavelenght | 1550nm |
| Distance | 10km |
| Transmitter | EML |
| Receiver | PIN |
| DDM/DOM | Yes |
| Media | SMF |
| Operating Temperature | 0°C to +75°C |
Competitive Advantages:
1. Excellent quality and 3 years warranty
2. Competitive pricing
3. OEM/ODM Customized label
4. Keep stock,Fast delivery
